Vacuum Interrupter 1.14KV 630A HCJ5 for vacuum contactor from JUCRO Electric

vacuum interrupter accept customized order design for you

Product Detail

Vacuum Interrupter 1.14KV 630A HCJ5 for vacuum contactor from JUCRO Electric


Brief introduction

The vacuum interrupter adoption porcelain and ceramics makes to insulate the outer shell. Contact is WCCu metal alloy material advanced technique of adoption Including bulk small. Breaking the abiliting strong the life span is long, maintenanle is simple, no explosion dangerous, no contaminate and the noise is low. It is extensive to used for coal mine , chemical engineering, Petroleum metallurgy etc. department, more than keeping with at the multifarious operation with the bad place usage of environment



Vacuum Tube main technical parameter

No.

Parameter name

Unit

Value

1

Rated voltage

kV

1.14

2

Rated current

A

630

3

Rated frequency

Hz

50

4

Rated making current

A

6300

5

Rated breaking current

A

5040

6

Limiting breaking current

A

6300

7

Rated short-time withstand current

A

5040

8

Rated short-time withstand voltage

kV

10

9

Mechanical life

times

1000000

10

Breaking operations

AC3

times

150000

AC4

6000

11

Automatic closing force of the contacts

N

70±20

12

Force required to hold contacts open at full stork

N

90±20

13

Circuit resistance at lowest rated contacts force

μΩ

≤80

14

Limiting abrasion of contacts

mm

2

15

Storage life

year

20

16

Internal gas pressure

Pa

≤1.33×10 -3
