Vacuum contactor 1000A 1.14KV HVJ5 from JUCRO Electric

vacuum contactor 1000A

Product Detail

Vacuum contactor 1000A 1.14KV HVJ5 from JUCRO Electric


1.  General

HVJ5-1.14/1000 AC vacuum contactor is designed for long-distance making and breaking of circuit, frequent starting and controlling of AC motors in the power systems, with AC 50Hz-60Hz, rated voltage of 1,140V and rated current to 1000A. It also can be equipped with thermal relay and all kinds of protection apparatus like electromagnetic starter, especially applied to explosion-proof starter and so on.

2.Main technical parameter

Product model

Rated voltage (V)

Rated currentMain circuitA

Main contacts parameters

Power frequency voltage
resistance V(effective value)


Main circuit

Control circuit

Opening distancemm

Over travel
(mm)

Final pressure
(N)


Main circuit

Auxiliary circuit

Control circuit


HVJ5-1.14/1000

1140

36.110.220.380

1000

2±0.2

1±0.2

30±3

4200

2500

2000




Product model

Making capacity

Breaking capacity

Limit breaking current(A)

Electricity life times

Mechanical life times

Overload capacity

AC3

AC4

HVJ5-1.14/1000

10Ie,100times

8Ie,25times

10000,3times

60*10 4

1.5*10 4

300*10 4

8Ie 10S

 Remark:Ie”is Rated current of main circuit.
