Vacuum Interrupter 7.2KV and 12KV 400A & 800A for VSC vacuum contactor use from JUCRO Electric

Vacuum Interrupter
Rated voltage: 7.2kV/ 12KV
Rated current: 400A/800A
Model: VAC1/VS2/VAS2
Brand: JUCRO

Product Detail

Vacuum Interrupter 7.2KV and 12KV 400A & 800A for VSC vacuum contactor use from JUCRO Electric

Operating characteristics •

Ambient temperature: – 5 °C ... + 40 °C

• Relative humidity: < 95% (without condensation)

• Altitude: < 1000 m s.l.m.


Vacuum Interrupter Model

VAC1

VS2

VAS2

Rated voltage

7.2KV

12KV

12KV

Rated current

400A

400A

800A

Rated breaking current

4KA

4KA

4KA

Rated power frequency withstand voltage

20KV

42KV

48KV

Rated lightning impulse withstand voltage

60KV

75KV

85KV

Mechanical life

1,000,000

1,000,000

1,000,000
